Series 4000 - Plugs

Description:

3/8in. Nominal

Coupling Category

One-Way Couplings

Manufacturer

Hansen

Male End Connections
Female End Connections
Part.No.
Thread
Dimensions
Part.No.
Thread
Dimensions
Steel
Size
C
D
HEX
Steel
Size
C
D
HEX
38
1/8-27 NPTF
1.72
0.72
0.63
41
1/4-18 NPTF
1.63
0.79
0.69
40
1/4-18 NPTF
1.88
0.72
0.63
41G†
1/4-18 NPTF
2.56
0.77
0.69
40G†
1/4-18 NPTF
2.65
0.77
0.69
43
3/8-18 NPTF
1.81
0.94
0.81
42
3/8-18 NPTF
1.88
0.79
0.69
43G†
3/8-18 NPTF
2.62
0.84
0.75
42G†
3/8-18 NPTF
2.65
0.77
0.69
45
1/2-14 NPTF
2.06
1.15
1.00
44
1/2-14 NPTF
2.09
1.01
0.88
Brass

Brass

B-43
3/8-18 NPTF
1.81
0.91
0.81
B-40
1/4-18 NPTF
1.88
0.70
0.63

B-42
3/8-18 NPTF
1.88
0.77
0.69


hosetem End Connections
Hose Clamp End Connections
Part.No.
Hose I.D.
Dimensions
Part.No.
Hose
Dimensions
Steel
C
D
Steel
I.D.
O.D.
C
D
HEX
404
1/4"
2.34
0.63
4-PB1
1/4"
15/32"
2.44
0.70
0.63
406
3/8"
2.34
0.63
4-PB3
1/4"
1/2"
2.44
0.70
0.63
408
1/2"
2.34
0.81
4-PB5
1/4"
9/16"
2.44
0.77
0.69
Brass

4-PB7
1/4"
5/8"
2.44
0.84
0.75
B-406
3/8"
2.34
0.63
4-PB9
1/4"
11/16"
2.44
0.91
0.81

4-PB11
1/4"
3/4"
2.44
0.98
0.88

4-PD5
3/8"
9/16"
2.56
0.77
0.69

4-PD7
3/8"
5/8"
2.56
0.84
0.75

4-PD9
3/8"
11/16"
2.56
0.91
0.81

4-PD11
3/8"
3/4"
2.56
0.98
0.88

4-PD13
3/8"
13/16"
2.56
1.05
0.94

4-PD15
3/8"
7/8"
2.56
1.12
1.00

4-PP13
1/2"
13/16"
3.25
1.05
0.94

4-PP15
1/2"
7/8"
3.25
1.12
1.00

4-PP17
1/2"
15/16"
3.25
1.19
1.06

4-PP19
1/2"
1"
3.25
1.26
1.13

† With Bleeder Ball Check – Reduces hose whip when disconnecting.
All dimensions in inches.
