Key Fire Hose
FLAME OUT MSHA Single Jacket

Application:

Key Fire “Flame Out” MSHA approved single jacket fire hose designed specifically for underground mine applications.

600 Pound Test Heavy Duty Lightweight
MSHA approved
Extruded Tube File #18-FHA080002
1-1/2" & 2"
1 year warranty
Abrasion Resistance
Cold Resistance
Heat Resistance
Self Extinguishing
Flame Resistant

PROUDLY MADE IN THE USA

Quality:

The fire hose assembly supplied under this specification shall be constructed with superior quality materials. NFPA 1961 standards shall be observed in production of the assembly, in order to ensure its quality and durability. Hose furnished under these specifications will have a potential service life warranty of one year; barring mistreatment that would render it unfit for service. Upon delivery, the hose shall be free from defects in workmanship and materials. Any defective hose will be replaced at no charge.

Jacket Construction

The single jacket will be woven evenly and be free of defects, including knots lumps or unsightly disfigurations that could jeopardize the integrity of the hose assembly. The warp yarn shall consist of staple polyester yarn. The use of filament or entangled yarn is expressly forbidden due to the lack of inherent abrasion resistance. The filler yarns shall be constructed of high strength, low elongation, filament polyester to reduce weight and increase flexibility.

Lining

The lining shall be a single-ply extruded tube of synthetic polyurethane based material to resist ozone. This special MSHA approved material shall adhere to the jacket by vulcanization process to prevent delamination and/or hydrolysis. The finished product will meet and exceed all MSHA specifications and be listed with File #18-FHA080002. This product is designed with self-extinguishing characteristics meeting MSHA standards. Neoprene or other rubber products that give off chlorine or other toxic gases shall not be acceptable.

Hydrostatic UL Testing

Service test pressure shall pass 300 PSI. Acceptance test pressure shall pass 600 PSI. Curve and straight burst testing shall 900 PSI.All testing shall be in accordance with NFPA1962 and UL-19 procedures.

Finished Hose

Printed letters with the words "Flame-resistant USMSHA 18-FHA080001" must be premanently marked on the product with letters at least 1/4" high and at intervals not exceeding 3 feet. NFPA approved markings shall be stenciled 4 feet from each end.

Couplings

Internal expansion ring threaded couplings or as required by purchaser.

** Customers are advised special diameters or construction characteristics may be produced
by special request. For more information please contact your JGB Sales Representative.

Weights and Measures

Size	Part No.	Service Test	Proof Test	Burst Test	Bowl Size	Weight/50'	Request Quote
1 1/2"	SP15-MSHA	300 psi	600 psi	900 psi	1 3/4"	12 lbs.	Request Quote
2"	SP20-MSHA	300 psi	600 psi	900 psi	2 1/4"	17 lbs.	Request Quote
2 1/2"	SP25-MSHA	300 psi	600 psi	900 psi	2 3/4"	23 lbs.	Request Quote
