Series 3RL - Plugs
Description:
3/8in. Nominal
Coupling Category
One-Way Couplings
Manufacturer
Hansen
|
Male End Connections
|
Female End Connections
|
||||||||
|
Part.No.
|
Thread
|
Dimensions
|
Part.No.
|
Thread
|
Dimensions
|
||||
|
Steel
|
Size
|
C
|
D
|
HEX
|
Steel
|
Size
|
C
|
D
|
HEX
|
|
3-L10
|
1/8-27 NPTF
|
1.54
|
0.72
|
0.63
|
3-L16
|
1/4-18 NPTF
|
1.48
|
0.79
|
0.69
|
|
3-L15
|
1/4-18 NPTF
|
1.7
|
0.72
|
0.63
|
3-L16G†
|
1/4-18 NPTF
|
2.39
|
0.98
|
0.88
|
|
3-L15G†
|
1/4-18 NPTF
|
2.64
|
0.98
|
0.88
|
3-L21
|
3/8-18 NPTF
|
1.63
|
0.94
|
0.81
|
|
3-L20
|
3/8-18 NPTF
|
1.76
|
0.79
|
0.69
|
3-L21G†
|
3/8-18 NPTF
|
2.64
|
0.98
|
0.88
|
|
3-L20G†
|
3/8-18 NPTF
|
2.64
|
0.98
|
0.88
|
3-L26
|
1/2-14 NPTF
|
2.25
|
1.15
|
1.00
|
|
3-L25
|
1/2-14 NPTF
|
2.31
|
1.01
|
0.88
|
3-L26G†
|
1/2-14 NPTF
|
2.91
|
0.98
|
0.88
|
|
3-L25G†
|
1/2-14 NPTF
|
2.83
|
0.98
|
0.88
|
3-L31
|
3/4-14 NPTF
|
2.25
|
1.37
|
1.19
|
|
3-L30
|
3/4-14 NPTF
|
2.38
|
1.23
|
1.06
|
|||||
|
3-L30G†
|
3/4-14 NPTF
|
2.88
|
1.19
|
1.06
|
|||||
|
hosetem End
Connections
|
Hose Clamp End
Connections
|
||||||||
|
Part.No.
|
Hose I.D.
|
Dimensions
|
Part.No.
|
Hose
|
Dimensions
|
||||
|
Steel
|
C
|
D
|
Steel
|
I.D.
|
O.D.
|
C
|
D
|
HEX
|
|
|
3-L17
|
1/4"
|
2.16
|
0.63
|
3-L23D5
|
3/8"
|
9/16"
|
2.45
|
0.77
|
0.69
|
|
3-L195
|
5/16"
|
2.16
|
0.63
|
3-L23D7
|
3/8"
|
5/8"
|
2.45
|
0.84
|
0.75
|
|
3-L195G†
|
5/16"
|
3.11
|
0.98
|
3-L23D9
|
3/8"
|
11/16"
|
2.45
|
0.91
|
0.81
|
|
3-L22
|
3/8"
|
2.16
|
0.75
|
3-L23D11
|
3/8"
|
3/4"
|
2.45
|
0.98
|
0.88
|
|
3-L22G†
|
3/8"
|
3.11
|
0.98
|
3-L23D13
|
3/8"
|
13/16"
|
2.45
|
1.05
|
0.94
|
|
3-L27
|
1/2"
|
2.16
|
0.81
|
3-L23D15
|
3/8"
|
7/8"
|
2.45
|
1.12
|
1.00
|
|
3-L27G†
|
1/2"
|
3.11
|
0.98
|
3-L28P13
|
1/2"
|
13/16"
|
3.14
|
1.05
|
0.94
|
|
3-L32
|
3/4"
|
3.13
|
1.00
|
3-L28P15
|
1/2"
|
7/8"
|
3.14
|
1.12
|
1.00
|
|
3-L32G†
|
3/4"
|
3.96
|
0.98
|
3-L28P17
|
1/2"
|
15/16"
|
3.14
|
1.19
|
1.06
|
|
3-L28P19
|
1/2"
|
1"
|
3.14
|
1.26
|
1.13
|
||||
|
3-L33R23
|
3/4"
|
1-1/8"
|
3.56
|
1.40
|
1.25
|
||||
|
3-L33R25
|
3/4"
|
1-3/16"
|
3.56
|
1.47
|
1.31
|
||||
|
3-L33R27
|
3/4"
|
1-1/4"
|
3.56
|
1.54
|
1.38
|
||||
| † With Bleeder Ball Check – Reduces hose whip when disconnecting. All dimensions in inches. |
 |
