Kuriyama
Kuri Tec A4176 Series Conductive PVC Air Hose with Polyurethane Cover

Types:
Air and Multipurpose Hose

Vendor: Kuriyama

Application:

Uniquely different PVC air hose that prevents static build-up without the need of a static wire.

• In-plant air service where static dissipation is required.
• Air lines for painting equipment.
• Applications requiring the use of grounded pneumatic tools.

Features

• Continuous flexible conductive liner assures contact with fittings, without special preparation or clamping techniques.
• No wires to break when the hose is flexed.
• Distinctive color and branding allows easy identification.
• Silicone-free.
• One-piece lengths.
• Branded as "Conductive Air".
• Excellent chemical and abrasion resistance afforded by polyurethane cover.
• Non-marking non-perforated cover.
• Phthalate Free!

Electrical Data:

• Resistance is less than 100,000 ohms per foot when tested with an ohmmeter, with normal open-circuit output voltage of 500 VDC.
• NOTE: Conductivity is through the inner liner only. To dissipate static electricity, the hose must be fitted with a grounded conductive coupling. When measured through the wall of the hose, the product demonstrates electrical insulation.

Tube:

Co-extruded electrically-conductive PVC.

Reinforcement:

Spiral polyester yarn

Cover:

Blue polyurethane for superior abrasion resistance.

Temperature:

14 to 150 ºF
-10 to 65 ºC

Packaging:

Coils / Reels

Lengths:

100 ft. / 500 ft.

Category:

Kuri Tec®

Colors:

Blue

Item #	Series No.	Size Code	Nominal ID		Nominal OD		†Max. Working Pressure at 70 ºF (20 ºC)	†Max. Working Pressure at 122 ºF (50 ºC)	Standard Length Coils	Approx. Wt. Per Pkg.	Request a Quote
A4176-04X500	A4176	4	1/4 in	6.5 mm	0.500 in	12.7 mm	300 psi	180 psi	500 ft	44 lb	Request Quote
A4176-04X100	A4176	4	1/4 in	6.5 mm	0.500 in	12.7 mm	300 psi	180 psi	100 ft	8 lb	Request Quote
A4176-06X500	A4176	6	3/8 in	9.5 mm	0.625 in	15.9 mm	300 psi	180 psi	500 ft	58.0 lb	Request Quote
A4176-06X100	A4176	6	3/8 in	9.5 mm	0.625 in	15.9 mm	300 psi	180 psi	100 ft	11 lb	Request Quote
A4176-08X500	A4176	8	1/2 in	12.7 mm	0.813 in	20.7 mm	300 psi	180 psi	500 ft	93.0 lb	Request Quote
A4176-08X100	A4176	8	1/2 in	12.7 mm	0.813 in	20.7 mm	300 psi	180 psi	100 ft	18.00 lb	Request Quote

Phthalate Free⁽¹⁵⁾
