Gates
Water Master® Slurry 150D AR

Types:
Water Hose     Sub Type: Water Discharge Hose

Vendor: Gates

Application:

Water and slurry discharge in heavy–duty industrial applications where abrasion–resistance is necessary.

Design Factor:

3:1

Max. W.P.:

150 psi (10.3 Bar)

Tube:

Type D (SBR). Black.

Reinforcement:

Multiple plies of synthetic, high tensile textile.

Cover:

Type D (SBR). Black with blue stripe. Abrasion–resistant.

Temperature:

-40°F to +150°F (-40°C to +66°C) continuous service.

Packaging:

Pallet

Couplings:

Contact JGB for proper hose fitting requirements.

Item No.	Nom. I.D.		Nom. O.D.		Vac.	MBR	Wt. Per Ft.	Request a Quote
	ln.	mm	ln.	mm	ln. Hg.	ln.	Lbs.
3135-2651	1-1/2	38.1	1.98	50.3	—	12	.70	Request Quote
3135-2652	1-5/8	41.3	2.10	53.3	—	15	.74	Request Quote
3135-2653	1-7/8	47.6	2.35	59.7	—	15	.88	Request Quote
3135-2654	2	50.8	2.48	63.5	—	20	.93	Request Quote
3135-2655	2-1/2	63.5	2.99	76.0	—	25	1.14	Request Quote
3135-2656	3	76.2	3.49	88.7	—	36	1.37	Request Quote
3135-2661	3	76.2	3.49	88.7	—	36	1.37	Request Quote
3135-2657	3-1/2	88.9	3.99	101.4	—	42	1.60	Request Quote
3135-2658	4	101.6	4.49	114.1	—	48	1.85	Request Quote
3135-2659	4-1/2	114.3	5.01	127.3	—	54	2.16	Request Quote
3135-2660	6	152.4	6.51	165.4	—	72	2.84	Request Quote
